TEP 160WIRCM Series
£0.00
SKU: TEP 160WIRCM Series
The TEP 160WIRCM Series is a family of isolated high performance DC/DC converter
modules with ultra-wide 4:1 input voltage ranges. They come in chassis
mount version with screw terminal block. A very high efficiency allows full power
operation without forced air cooling at 25°C. The very wide input voltage range
makes these converters interesting solution for battery operated systems.
Typical applications are in telecom/datacom, industry control and railway systems
for on board power distribution.
• Chassis mount with screw terminal block
• Ultra wide 4:1 input voltage ranges 9–36, 18–75, 43–160 VDC
• EN 50155 approval for railway applications
• Very high efficiency up to 91%
• No minimum load
• Soft start
• Adjustable output voltage +10 / -20%
• Sense line
• Remote On/Off input
• Under voltage lock-out circuit
• 3-year product warranty
