TEP 40UIR Series
£0.00
SKU: TEP 40UIR Series
The TEP 40UIR is a series of high performance 40 Watt railway DC/DC
converters with ultra wide 12:1 input voltage range featuring a compact ¼ brick
(2.3”x1.45”x0.5”) metal package. The ultra wide input allows the converter to
act as an all-in-one solution if different voltage ranges have to be covered in the
same application, resolving the issue of having multiple different converters
installed. An internal circuit implemented in these modules helps to extend the
hold-up time with ease as it eliminates the need of expensive high voltage
capacitors to cover the full input range. With only a 25V capacitor (independent
of the input voltage) the whole input range can be covered effectively reducing
cost, size and inrush current. All models are approved for railway applications
according to EN 50155, EN 61373, EN 45545-2 and offer standard features
such as high efficiency up to 91%, an operating temperature range of -40° to
+85°C and an I/O-isolation voltage of 3’000 VAC. An adjustable under voltage
lockout function, remote on/off and adjustable outputs round out the features
and ensure that these converter modules fit in any application setup.
• Ultra-wide 12:1 input voltage range 9–75, 14–160 VDC
• Compact 2.3”x1.45”x0.5” standard package (quarter brick)
• Bus pin to easily extend hold-up time
• EN 50155 and EN 61373 approval for railway applications
• Qualification for fire behaviour according to EN 45545-2
• Operating temperature range –40°C to +85°C
• I/O-isolation 3‘000 VAC
• High efficiency up to 91%
• Adjustable output voltage, Remote On/Off and adjustable under voltage lockout
• 3-year product warranty
