TEP100 Series
£0.00
SKU: TEP100
The TEP 100 Series is a family of isolated high performance DC/DC converter
modules with ultra-wide 2:1 input voltage ranges which come in a rugged, sealed
metal case. These converters are suitable for a wide range of applications.
For easy connection there is also an unique adaptor available with screw terminals.
A very high efficiency allows an operating temperature up to +60°C with
natural convection cooling without power derating. Further features include output
voltage trimming, Remote On/Off and under voltage lockout. The very wide
input voltage range make these converters also an interesting solution for battery
operated systems.
• Rugged, compact metal case
• Screw terminal adaptor available for easy connection
• Wide 2:1 input voltage range
• Full load operation up to 60°C with convection cooling
• Soft start
• Under voltage lock-out circuit
• Input protection filter
• 3-year product warranty
