TEP100UIR Series
£0.00
SKU: TEP100UIR Series
The TEP 100UIR is a series of high-performance 100 Watt DC/DC converters
with an ultra-wide 12:1 input voltage range. The TEP 100UIR comes in a
compact, fully encapsulated quarter-brick (2.3”x1.45”x0.5”) package for
highest reliability. The ultra-wide input voltage range lets system builders
reduce the number of design channels where otherwise multiple input voltage
configurations would be required. Thanks to its dedicated holdup circuit, the
TEP 100UIR complies with extended holdup-time requirements without the
need for bulky capacitors. The TEP 100UIR is EN 50155 certified for rolling
stock applications, EN 61373 certified for mechanical shock and vibration and
EN 45545-2 certified for fire behaviour. It comes with IEC/EN/UL 62368-1
safety approvals.
• Ultra-wide 12:1 input voltage range: 9–75, 14–160 VDC
• EN 50155 and EN 61373 certified
• Encapsulated quarter-brick (2.3”x1.45”x0.5”) package
• Extended holdup time with lowest capacitor volume
• EN 45545-2 fire behavior
• –40°C to +85°C operating temperature
• Up to 3‘000 VAC I/O-isolation
• Remote on/off and trim function
• Adjustable undervoltage lockout (UVLO), short-circuit protection (SCP), overvoltage protection (OVP) and
overtemperature protection (OTP)
• 3-year product warranty
