TEP150WI-F Series
£0.00
SKU: TEP150WI-F Series
The modules have originally been designed for harsh industrial environment.
High EMC immunity against surge, burst, radiated and conducted disturbances
and the shock/ vibration and thermal shock resistance make them very popular
for stringent requirements. With the extended input voltage ranges that cover
the nominal 24, 36, 72 and 110 VDC with ±40 % tolerance and the approval
in accordance to EN 50155 standard they now also offer a reliable solution for
mobile and stationary railway applications. At 100% load the current
characteristics goes from constant voltage to constant current what makes the
units also suitable for battery charger applications. With protection against
over-temperature, overload, short-circuit, overvoltage and input under-voltage
lock-out they are hard to destroy.
• Shielded metal case with screw terminals
• Ultra wide 4:1 input voltage ranges 9–36, 18–75, 43–160 VDC
• EN 50155 approval for railway applications
• Very high efficiency up to 89%
• Constant current output characteristic for battery load applications
• With input filter for EN 55032 class B
• Wide Operating temperature range: –40°C to +75°C
• Under voltage lock-out & overtemperature protection
• Easy chassis and wall mounting
• 3-year product warranty
