TEP75WICM Series
£0.00
SKU: TEP75WICM Series
The TEP 75WICM Series is a family of isolated high performance DC/DC converter
modules. They come in chassis mount version with screw terminal block.
These converters are suitable for a wide range of applications, but the product
is designed particularly also for industrial applications where often no PCB mounting
is possible but the module has to be mounted on a chassis. Four threaded
M3 inserts in the module makes chassis mount or attachment of a heatsink
for optimal thermal management very simple. For easy connection there is also
an unique adaptor available with screw terminals. A very high efficiency allows
an operating temperature up to +60°C with natural convection cooling without
power derating. Further features include output voltage trimming, Remote On/-
Off and under voltage lockout. The very wide input voltage range makes these
converters also an interesting solution for battery operated systems.
• Chassis mount with screw terminal block
• EN 50155 approval for railway applications
• Optional DIN-rail mounting kit
• Ultra wide 4:1 input voltage range
• Full load operation up to +60°C with convection cooling
• Undervoltage lockout
• Input protection filter
• 3-year product warranty
