TEP75WICMF Series
£0.00
SKU: TEP75WICMF Series-1
The TEP 75WICMF Series is a family of isolated high performance DC/DC converter
modules with ultra-wide 4:1 input voltage ranges. They come in chassis
mount version with screw terminal block. These converters are suitable for a
wide range of applications, but the product is designed particularly also for industrial
applications where often no PCB mounting is possible but the module
has to be mounted on a chassis. Four threaded M3 inserts in the module makes
chassis mount or attachment of a heatsink for optimal thermal management
very simple. For easy connection there is also an unique adaptor available with
screw terminals. A very high efficiency allows an operating temperature up to
+60°C with natural convection cooling without power derating. Further features
include output voltage trim, Remote On/Off and under voltage lockout.
The very wide input voltage range makes these converters also an interesting
solution for battery operated systems.
• Chassis mount with screw terminal block
• EN 50155 approval for railway applications
• Optional DIN-rail mounting kit
• Ultra wide 4:1 input voltage range
• Full load operation up to +60°C with convection cooling
• Undervoltage lockout
• Input protection filter
• 3-year product warranty
