TES 2M Series
£0.00
SKU: TES 2M
The TES 2M series is range of compact 2W DC/DC-converters providing a high I/O-isolation voltage of 4000 VAC. With a reinforced I/O-isolation system this product is an economical solution for many applications in instrumentation, industrial controls, medical equipment and everywhere where supplementary-or reinforced insulation is required. These converters are qualified for high solder temperature profiles in leadfree solder processes. For automated SMD production lines the devices can be supplied in tape & reel package. Full SMD-design with exclusive use of ceramic capacitors ensure a very high reliability and a long product lifetime.
• Supplementary and reinforced insulation
• I/O isolation 4000 VACrms rated for 300 Vrms working voltage
• Unregulated outputs
• 2 x MOOP Medical safety
• Industrial safety to UL/IEC/EN 62368-1
• Ultracompact SMD-package
• Operating temp. range –25°C to +80°C
• Qualified for leadfree reflow solder process
• Available in tape & reel package
• 3-year product warranty
