TES 5WI Series
£0.00
SKU: TES 5WI
The TES 5WI series is a family of high performance 5W DC/DC converter modules in a low profile SMD package with compact dimensions. The 14 modules feature ultrawide 4:1 input ranges with tightly regulated output voltage. High efficiency allows an operating temperature range of –40 to+70°C at full load. Further features are built-in EMI-filter to meet EN 55032 conducted class A without external components and remote On/Off control. The products comply with IPC J-STD-020D and are qualified for high temperature lead-free reflow solder process
• Compact SMD package
• 33.4 x 25.6 mm footprint
• Ultra-wide 4:1 input voltage range
• I/O isolation 1500 VDC
• Operating temp. range – 40°C to +70°C
• Short circuit protection
• Input filter to meet EN 55032, conducted class A
• Remote On/Off
• High accuracy of pin co-planarity
• 3-year product warranty
