THB 3 Series
£0.00
SKU: THB 3
The THB 3 series is a range of high performance, regulated DC/DC converters in a DIP-24 plastic package. A reinforced I/O-isolation system and a wide 2:1 input voltage range make this product the best choice for many demanding applications like transportation systems, industrial controls, medical equipment, instrumentations, everywhere where high basic-, supplementary-or reinforced insulation is required to meet requested safety standards. A high efficiency allows safe operation in a temperature range of –40°C to +85°C. Other features of this product are over voltage protection and internal EMI-input filter to meet EN 55022, class A without additional components. Full SMD-design with exclusive use of ceramic capacitors ensure a very high reliability and a long product lifetime.
• Supplementary and reinforced insulation
• I/O isolation 4800 VACrms rated for 1000 Vrms (1410 Vpk) working voltage
• Medical safety to ES 60601-1 and IEC/EN 60601-1 3rd edition, 2 x MOOP
• Isolation test voltage 6000 Vpk
• Wide 2:1 input voltage ranges
• Extended operating temperature range – 40°C to 85°C max.
• Input filter meets EN55022, class A
• Continuous short-circuit protection
• High reliability
• 3-year product warranty
