THD 12 Series
£0.00
SKU: THD 12
The THD 12 series is a range of high performance, isolated 12W DC/DC converters. They come in a low profile, DIP-24 package with standard industry pin-out. Overload and overvoltage protection as well as remote On/Off are included as standard. Built-in filters for both input and output minimizes the need of external filtering. Full SMD-design with exclusive use of ceramic capacitors guarantees a high reliability and long product lifetime. Typical applications for these converters are industrial electronics, instrumentation, data communication systems and battery operated equipment with limited space available on the PCB
• Wide 2:1 input range
• Very high efficiency up to 88%
• I/O isolation 1500V
• Input filter meets EN 55032, class A
• Remote On/Off
• Under voltage lock-out circuit
• Shielded metal case with insulated Baseplate
• Continuous short-circuit protection
• Operating temp. range –40°C to +85°C (with derating)
• 3-year product warranty
