THD 15N Series
£0.00
SKU: THD 15N
The THD 15N series models provide 15 Watt output power out of a very compact shielded metal case that occupies only 1 inch² of board space. The converters work with a high efficiency over the full load range and draw a very low input current at no load conditions. All models have a wide 2:1 input voltage range and a precisely regulated output voltage. Typical applications for these converters are mobile equipment, instrumentation, distributed power architectures in communication and industrial electronics and everywhere where space on PCB is critical
• Highest power density in DIP 24 package
• Shielded metal case with isolated Baseplate
• Very high efficiency up to 91%
• Wide 2:1 input ranges
• No minimum load required
• Input filter meets EN 55022 class A without external components
• I/O isolation voltage 1500 VDC
• Operating temp. range : –40°C to + 85°C
• Remote On/Off control
• Industry standard pinout
• 3-year product warranty
