THI 2M Series
£0.00
SKU: THI 2M
The THI 2M series is a new range of ultra-compact 2W DC/DC-converters providing a high I/O-isolation voltage of 3000 VAC. With a reinforced I/O-isolation system this product is an economical solution for many applications in instrumentation, industrial controls, medical equipment and everywhere where supplementary- or reinforced insulation is required to meet requested safety standards. Full SMD-design with exclusive use of ceramic capacitors ensure a very high reliability and a long product lifetime.
• DIP-16 Package
• Unregulated outputs
• I/O isolation 3000 VAC rms rated for 300 Vrms working voltage
• Medical safety to UL 60601-1 and IEC/EN 60601-1 3rd edition, 2 x MOOP
• Industrial safety to IEC/EN/UL 62368-1
• Operating temp. range –25°C to +80°C
• 3-year product warranty
