THL 10 Series
£0.00
SKU: THL 10
The THL 10 is a series of industrial 10 Watt DC/DC-converters packed in the compact 1" x 1" case and is a pin to pin replacement for the popular 1" x 2" size products. The industrial standard pinout, the wide 2:1 input voltage range and the input filter that meets EN 55032 Class A (conducted) without external components make these converters easy to design in and suitable for to cost optimize many existing and new applications.
The models have short circuit and overvoltage protection and are applicable in temperature ranges of up to +80°C or +85°C with optional mounted heat sink. Typical applications are instrumentation, distributed power architectures in communication and industrial electronics.
• 10 Watt in 1” x 1” package
• Shielded metal case with isolated baseplate
• Wide 2:1 input voltage ranges
• Operating temp. range –40°C to +80°C and up to +85°C with heat-sink
• I/O isolation voltage 1500 VDC
• Input filter meets EN 55022 class A without external components
• Cost optimized design
• Industry standard pinout
• 3-year product warranty
