THL 15WI Series
£0.00
SKU: THL 15WI Series
The THL 15WI series is Traco Power's latest addition to the existing 15 Watt
DC/DC converter range. With the focus on combining cost efficiency and quality
this isolated high performance 15 Watt DC/DC converter is suitable for many
different applications. The series comes in an encapsulated, shielded 1" x 1" x
0.4" metal package and has a fully integrated EN 55032 class A filter. High efficiency
up to 91% enables the converter to operate from –40°C to +70°C without
derating. All models have an ultra wide 4:1 input voltage range and precisely
regulated, isolated outputs. The series meets the latest IT safety certifications
(UL 62368-1) and is thus eligible for uses in mobile equipment, instrumentation,
distributed power architectures in communication and industrial electronics
and everywhere where cost efficiency and quality are critical factors.
• 15 Watt converter in a 1" x 1" metal package
• Cost efficient design
• Ultra wide 4:1 input voltage range: 9-36 and 18-75 VDC
• Operating temperature range -40 to +70 °C without derating
• Internal EN 55032 class A filter
• 1'500 VDC I/O-isolation
• Protection against overvoltage, overload and short circuit
• Remote On/Off and trim function
• Optional heatsink for increased temperature capabilities
• 3-year product warranty
