THL 40WI Series
£0.00
SKU: THL 40WI Series
The THL 40WI series extends Traco Power’s existing DC/DC converter portfolio
with 40 Watt, 1” x 1” package converters. With the focus on combining cost
efficiency and quality this isolated high performance DC/DC converter series is
suitable for many different applications. The series comes in an encapsulated,
shielded 1” x 1” x 0.43” metal package and offers integrated remote on/off and
trim functions. High efficiency up to 93% enables the converter to operate from
–40°C to +65°C without derating. All models have a wide 4:1 input voltage
range and precisely regulated, isolated outputs. The series meets the latest IT
safety certifications (UL 62368-1) and is suitable for uses in mobile equipment,
instrumentation, distributed power architectures in communication and
industrial electronics and everywhere where cost efficiency and quality are
critical factors.
• 40 Watt converter in a 1” x 1” metal package
• Cost efficient design
• Wide 4:1 input voltage range: 9-36 and 18-75 VDC
• Operating temperature range -40 to +65 °C without derating
• 1500 VDC I/O-isolation
• Protection against overload, overvoltage and short circuit
• Remote On/Off and Trim function
• Optional heatsink for increased temperature capabilities
• 3-year product warranty
