THL10 WI Series
£0.00
SKU: THL 10WI
The THL 10WI is a series of general purpose 10 Watt dc/dc-converters packed in the compact 1” x 1” case and is a pin to pin replacement for the popular 1” x 2” size products. The industrial standard pinout, the ultra wide 4:1 input voltage range and the input filter that meets EN 55022 Class A without external components make these converters easy to design in and suitable for to cost optimize many existing and new applications.
The models have a remote On/Off control, short circuit and overvoltage protection and are applicable in temperature ranges of up to +75°C or +85°C with optional mounted heat sink. Typical applications are instrumentation, distributed power architectures in communication and industrial electronics.
• 10 Watt in 1” x 1” package
• Shielded metal case with isolated baseplate
• Ultrawide 4:1 input voltage ranges
• Remote On/Off control
• Operating temp. range –40°C to +75°C and up to +85°C with heat-sink
• I/O isolation voltage 1500 VDC
• Input filter meets EN 55022 class A without external components
• Cost optimized design
• Industry standard pinout
• 3-year product warranty
