THN 10UIR Series
£0.00
SKU: THN 10UIR Series
The THN 10UIR is a series of high-performance DC/DC converters with an
ultra-wide 12:1 input voltage range and a power output of 10 watt. The THN
10UIR comes in a compact, fully encapsulated 1”x1” housing for highest
reliability and effective cooling. Thanks to its dedicated holdup capacitor
connection, the THN 10UIR meets extended holdup-time requirements without
the need for bulky input capacitors. The THN 10UIR is EN 50155 certified for
rolling stock applications, EN 61373 certified for resistance against mechanical
shock and vibration and EN 45545-2 certified for fire behavior. The THN 10UIR
also comes with IEC/EN/UL 62368-1 safety approvals for use in a wide range
of demanding industrial applications.
• Compact 1”x1” housing
• Ultra-wide 12:1 input range: 9-75, 14-160 VDC
• -40°C up to 80°C natural convection cooling without derating
• EN 50155, EN 45545-2 and EN 61373 certified
• Dedicated holdup capacitor connection
• Fully encapsulated
• 3000 VDC I/O isolation
• Remote on/off and trim function
• Protection against short-circuit, overvoltage and overtemperature
• 3-year product warranty
