THN 15N Series
£0.00
SKU: THN 15N
The THN 15N series is the latest generation of high performance 15 W DC/DC converters and comes in an encapsulated, shielded 1.0" x 1.0" x 0.4" metal package. The new and improved design allows to fully integrate an EN 55032 class A filter and greatly reduces the no-load power consumption (96-336 mW). Advanced circuit design and a high efficiency of up to 91% enable the THN 15N to operate in a temperature range of –40°C to +70°C without derating. All models have a wide 2:1 input voltage range and precisely regulated, isolated output voltages. Further features include remote On/Off and trimmable outputs. Together with the latest IT safety certifications (UL 62368-1) typical applications for these converters are mobile equipment, instrumentation, distributed power architectures in communication and industrial electronics and everywhere where space on PCB is critical.
• 15 Watt converter in a compact 1.0" x 1.0" metal package
• Wide 2:1 input voltage: 9- 18, 18-36, 36-75 VDC
• Internal EN 55032 class A filter
• Operating temperature range - 40 to +70 °C without derating
• Low no-load power consumption 96- 336 mW
• High efficiency up to 91%
• I/O-isolation voltage 1600 VDC
• Protection against overload, overvoltage and short circuit
• Remote On/Off and Trim function
• 3-year product warranty
