THN 15UIR Series
£0.00
SKU: THN 15UIR
The THN 15UIR is a series of high-performance DC/DC converters with an ultra-
wide 12:1 input voltage range and a power output of 15 watt. The THN 15-
UIR comes in a compact, fully encapsulated 1”x1” housing for highest reliability
and effective cooling. Thanks to its dedicated holdup capacitor connection, the
THN 15UIR meets extended holdup-time requirements without the need for bulky
input capacitors. The THN 15UIR is EN 50155 certified for rolling stock applications,
EN 61373 certified for resistance against mechanical shock and vibration
and EN 45545-2 certified for fire behavior. The THN 15UIR also comes
with IEC/EN/UL 62368-1 safety approvals for use in a wide range of demanding
industrial applications.
• Compact 1”x 1” housing
• Ultra-wide 12:1 input voltage range: 9–75, 14–160 VDC
• –40°C up to +70°C natural convection cooling without derating
• EN 50155, EN 45545-2 and EN 61373 certified
• Dedicated holdup capacitor connection
• Fully encapsulated
• 3000 VDC I/O isolation
• Remote on/off and trim function
• Protection against short-circuit (SCP), overvoltage (OVP) and overtemperature (OTP)
• 3-year product warranty
