THN 20UIR Series
£0.00
SKU: THN 20UIR
The THN 20UIR is a series of high-performance DC/DC converters with an ultra-
wide 12:1 input voltage range and a power output of 20 watt. The THN 20-
UIR comes in a compact, fully encapsulated 1”x1” housing for highest reliability.
The default variant features a pre-mounted heatsink for convection cooling
up to +70°C without derating. Thanks to its dedicated holdup capacitor connection,
the THN 20UIR meets extended holdup-time requirements without the
need for bulky input capacitors. The THN 20UIR is EN 50155 certified for rolling
stock applications, EN 61373 certified for resistance against mechanical shock
and vibration and EN 45545-2 certified for fire behavior. The THN 20UIR
also comes with IEC/EN/UL 62368-1 safety approvals for use in a wide range
of demanding industrial applications.
• Compact 1”x 1” housing
• Ultra-wide 12:1 input voltage range: 9–75, 14–160 VDC
• –40°C up to +70°C natural convection cooling without derating
• EN 50155, EN 45545-2 and EN 61373 certified
• Dedicated holdup capacitor connection
• Fully encapsulated
• 3000 VDC I/O isolation
• Remote on/off and trim function
• Protection against short-circuit (SCP), overvoltage (OVP) and overtemperature (OTP)
• 3-year product warranty
