THN 20WI Series
£0.00
SKU: THN 20WI
The THN 20WI series models are high performance DC/DC converters. They achieve 20 W output power and come in a small size metal casing (1.0" x 1.0" x 0.4"). The models feature an ultra-wide 4:1 input voltage range while the output voltages are precisely regulated even under no load conditions. Highest efficiency of up to 90% makes this product very reliable and applicable in temperature ranges of up to 85°C. The low no-load input current characteristics and the remote On/Off control make these converters an ideal solution for battery operated systems. Typical applications are in mobile equipment, instrumentation, distributed power architectures in communication and industrial electronics and everywhere where space on the PCB is critical.
• Ultra compact size: 1.0" x 1.0" x 0.4"
• Shielded metal casing with isolated baseplate
• Ultrawide 4:1 input voltage ranges
• Very high efficiency up to 90%
• Output voltage adjustable
• Remote On/Off control
• Operating temp. range –40°C to +75°C and up to 85 °C with heat-sink
• I/O isolation voltage 1600 VDC
• Input filter meets EN 55032 class A without external components
• 3-year product warranty
