THN 30WI Series
£0.00
SKU: THN 30WI
The THN 30WI series is the latest generation of high performance DC/DC
converter modules with highest power density. The product achieves 30 W
output power while it comes in a metal case with dimensions of only 1.0" x
1.0" x 0.4". All models have an ultra wide 4:1 input voltage range and precisely
regulated output voltages, even under no load conditions. Highest efficiency
across full load range makes this product very reliable and applicable in
temperature ranges of up to 85°C. With a low input current at minimal load and
remote On/Off control these converters are the ideal solution for
battery-operated systems. Typical applications are in mobile equipment,
instrumentation, distributed power architectures in communication and
industrial electronics and everywhere where space on the PCB is critical.
• Highest power density 30 W Converter! Ultra compact size: 1.0" x 1.0" x 0.4"
• Shielded metal case with isolated baseplate
• Ultrawide 4:1 input voltage range
• Very high efficiency across full load range up to 92%
• Over temperature protection
• Operating temp. range: –40°C to +80°C and up to 85°C with heat sink
• Ultra low no load input current
• Remote On/Off control and output voltage adjustable
• I/O isolation voltage 1600 VDC
• 3-year product warranty
