TMH Series
£0.00
SKU: TMH
The TMH series are ultra miniature, isolated 2 Watt DC/DC-converters in a Single-in-Line package (SIP). Requiring only 1.5 cm2 board space they offer the ideal solution in many space critical applications for board level power distribution. The use of SMD-technology makes it possible to offer a product with high performance at low cost.
• Industry standard pinout
• Unregulated outputs
• Operating temperature range –40 °C to
+ 85 °C
• I/O isolation voltage 1000 VDC
• Efficiency up to 83 %
• 3-year product warranty
