TMR 9 Series
£0.00
SKU: TMR 9
The TMR 9 series is a new family of isolated 9W DC/DC converter modules with
regulated output, featuring wide 2:1 input voltage ranges. The product comes
in a ultra-compact SIP-8 metal package with a small footprint occupying only
2.0 cm² (0.3 square inch) of board space.
An excellent efficiency allows –40° to +60°C operation temperatures without
derating. Further features include remote On/Off control and continuous short
circuit protection. The very compact dimensions of these converters make them
an ideal solution for many space critical applications in communication
equipment, instrumentation and industrial electronics.
• Highest power density in SIP-8 metal package (optional plastic package)
• Wide 2:1 input voltage range
• Temperature range –40° to +85°C
• High efficiency up to 89%
• Indefinite short-circuit protection
• I/O isolation 1600 VDC
• Remote On/Off control
• Fully RoHS compliant
• 3-year product warranty
