TMR-9WI Series
£0.00
SKU: TMR-9WI
The TMR 9WI series is a new family of isolated 9W DC/DC converter modules with regulated output, featuring ultra wide 4:1 input voltage ranges. The product comes in a ultra-compact SIP-8 metal package with a small footprint occupying only 2.0 cm² (0.3 square inch) of board space.
An excellent efficiency allows –40° to +60°C operation temperatures without derating. Further features include remote On/Off control and continuous short circuit protection. The very compact dimensions of these converters make them an ideal solution for many space critical applications in communication equipment, instrumentation and industrial electronics.
• Highest power density in SIP-8 metal package (optional plastic package)
• Ultra wide 4:1 input voltage range
• Temperature range –40° to +85°C
• High efficiency up to 89%
• Indefinite short-circuit protection
• I/O isolation 1'600 VDC
• Remote On/Off control
• Fully RoHS compliant
• 3-year product warranty
