TMV-EN Series
£0.00
SKU: TMV-EN
The TMV-EN series is a range of 1 Watt unregulated DC/DC converters with high I/O isolation. This product features an isolation barrier which is approved for supplementary an reinforced insulation. SMD construction and a special designed toroidal transformer made it possible to built these converters in a standard SIP package with a very small footprint. These features making the TMV-EN series an economical solution in many DC/DC converter applications requiring safety agency approval.
• Single-in-line package (SIP)
• Industrial safety to IEC/EN/UL 62368-1
• Reinforced insulation rated for 300 VAC working voltage
• I/O isolation voltage 3000 VACrms
• Operating temperature range –25 °C to + 85 °C
• Unregulated outputs
• 3-year product warranty
