TPI300-M Series
£0.00
SKU: TPI300-M Series
The TPI 300-M series is a set of AC/DC power supplies in an encased package
style. They feature a reinforced double I/O isolation (3000 VAC) system according
to latest industrial safety standards. The excellent efficiency of up to 93%
allows a high power-density and compact design (4.6” x 2.44”).
• High power-density: 300 Watt in 4.6”x2.44” package (encased)
• I/O isolation 3000 VAC rated for 250 VAC working voltage
• Certification according to IEC/EN/UL 62368-1
• Peak power operation up to 360 Watt for 5s
• Operating temperature –40°C to 80°C
• Active power factor correction >0.9
• Operating up to 5000m altitude
• High efficiency up to 93%
• Protection class II prepared
• 3-year product warranty
