TPI30A-J Series
£0.00
SKU: TPI30A-J Series
The TPI 30A-J is a 30 Watt AC/DC open frame power supplies series with a
4000 VDC reinforced isolation system. Our TPI line specifically focuses on providing
cost efficient industrial power supplies in compact designs. This series
offers a peak power function which enables the unit to deliver up to 130% of
the rated power for up to 10 seconds. Excellent efficiency of up to 90% allows
a compact design and an operating temperature range (natural convection) of
–40°C to +60°C without derating, while going up to +85°C with either load
derating or forced cooling. They are designed to meet the ErP directive (< 0.3
W no load power consumption) and come with an EMC characteristics dedicated
for applications in industrial/automation and test & measurement fields.
High reliability is provided by use of industrial high-quality grade components
and an excellent thermal management. It makes the TPI 30A-J an ideal solution
for any demanding industrial devices or space critical applications.
• 30 Watt open frame power supplies in a 3.34" x 1.36" package
• Compact and cost efficient design
• Peak power function up to 130%
• I/O reinforced isolation 4000 VDC
• Operating temperature range –40°C to +85°C
• No load input power <0.3W (acc. ErP directive)
• High efficiency up to 90%
• Internal EN 55032 class B filter
• Protection class II prepared
• 3-year product warranty
