TPP 100A-J Series
£0.00
SKU: TPP 100A-J Series
The TPP 100A-J series of 100 Watt AC/DC open frame power supplies feature
a reinforced double I/O isolation system according to latest medical safety standards
(60601-1 edition 3.2, 2 x MOPP). The earth leakage current is below
75 μA which makes the units suitable for BF (body floating) applications.
• Open frame 100 W power supply with JST connection in 2.0” x 3.0” package
• Certification according to IEC/EN/ES 60601-1 edition 3.2 for 2 x MOPP
• Low leakage current <75 μA rated for BF applications
• Risk management process according to ISO 14971 incl. risk management file
• Acceptance criteria for electronic assemblies acc. to IPC-A-610 Level 3
• Active power factor correction >0.95
• Protection class l and ll prepared
• Operating up to 5000 m altitude
• Ready to meet ErP directive, <0.3 W no load power consumption
• 5-year product warranty
