TPP 15-J Series
£0.00
SKU: TPP 15-J
Encapsulated single output 15 Watts AC/DC power supplies, earth leakage current is below 75 μA, IEC 60601-1-2The TPP 15-J AC/DC power supplies feature a reinforced double I/O isolation system according to medical safety standards IEC/EN/ES 60601-1 3rd edition
for 2 x MOPP approved for an operating altitude of 5000 m. The earth leakage current is below 75 μA which makes the units suitable for BF (body floating) applications.
The excellent efficiency of up to 88.5% offers a high power density in the packaging format 1.1” x 2.8”. The full load operating temperature range covers –40°C to +70°C while it goes up to 85°C with 50% load derating. The units operate in compliance to the medical EMC emission and immunity levels according to latest standard IEC 60601-1-2 4th edition.
