TPP 180A-M Series
£0.00
SKU: TPP 180A-M Series
The TPP 180A-M is series of open frame AC/DC power supplies coming in an
open frame package. They feature a reinforced double I/O isolation (4000 VAC)
system according to latest medical safety standards (60601-1 edition 3.2, 2 x
MOPP). The leakage current is below 100 μA and makes the units suitable for
BF (body floating) applications.
• High power-density: 180 Watt in 3”x 2” package (open frame)
• I/O isolation 4000 VAC rated for 250 VAC working voltage
• Certification according to IEC/EN/ES 60601-1 edition 3.2 for 2 x MOPP
• Risk management process according to ISO 14971 incl. risk management file
• Acceptance criteria for electronic assemblies acc. to IPC-A-610 Level 3
• Peak power operation up to 220 Watt for 5s
• Operating temperature –40°C to 85°C
• Active power factor correction >0.9
• Operating up to 5000m altitude
• 5-year product warranty
