TPP 300A-M Series
£0.00
SKU: TPP 180A-M Series-1
The TPP 300 series is a set of AC/DC power supplies in an open frame package
style. They feature a reinforced double I/O isolation (4000 VAC) system according
to latest medical safety standards. The TPP series also has a low leakage
current of <100 μA which makes the units suitable for BF (body floating)
applications.
• High power-density: 300 Watt in 4”x 2”package (open frame)
• I/O isolation 4000 VAC rated for 250 VAC working voltage
• Certification according to IEC/EN/ES 60601-1 edition 3.2 for 2 x MOPP
• Risk management process according to ISO 14971 incl. risk management file
• Acceptance criteria for electronic assemblies acc. to IPC-A-610 Level 3
• Peak power operation up to 360 Watt for 5s
• Operating temperature –40°C to 85°C
• Active power factor correction >0.9
• Operating up to 5000m altitude
• 5-year product warranty
