TPP 40E-J Series
£0.00
SKU: TPP 40E-J Series
The TPP 40E-J is a 40 Watt encapsulated AC/DC modules in a Chassis mount
package. It features a reinforced double I/O isolation system according to latest
medical safety standards (60601-1 edition 3.2, 2 x MOPP).
• Compact encapsulated 40 Watt Chassis mount module (4.3"x2.2")
• I/O isolation 4000 VAC rated for 250VAC working voltage
• Certification according to IEC/EN/ES 60601-1 edition 3.2 for 2 x MOPP
• Risk management process according toISO 14971 incl. risk management file
• Acceptance criteria for electronic assemblies acc. to IPC-A-610 Level 3
• Low leakage current <100 μA rated for BF applications
• Operating temperature –40°C to 80°C
• EMC compliance according to IEC 60601-1-2 4th edition and EN55032class B
• Operating up to 5000m altitude
• 5-year product warranty
