TPP 450BA-M Series
£0.00
SKU: TPP 450BA-M Series
The TPP 450BA-M Series of 450 Watt AC/DC power supplies features a reinforced
double I/O isolation system according to latest medical safety standards
(60601-1 edition 3.2, 2 x MOPP) and is suitable for class II applications. The
earth leakage current is below 100 μA what makes the units suitable for BF (body
floating) applications.
• High power density 3" x 5" open frame medical power supply
• Protection class II prepared
• 450 Watt with forced air cooling, up to 320 Watt convection cooled without derating up to 50°C
• Medical certification to IEC/EN/ES 60601-1 edition 3.2 for 2 x MOPP
• EMC compliance to IEC/EN 60601-1-2 4th edition
• Risk management process according to ISO 14971 incl. risk management file
• Isolation (4000 VAC) and leakage current (<100 μA) rated for BF applications
• Standard features: 5 V standby output 12 V fan output, Remote On/Off, Power Good Signal, variable fan speed
• Operating up to 5000 m altitude
• 5-year product warranty
