TPP 450BM Series
£0.00
SKU: TPP 450BM Series
The TPP 450B-M Series of 450 Watt AC/DC power supplies feature a
reinforced double I/O isolation system according to latest medical safety
standards (60601-1 edition 3.2, 2 x MOPP) and is suitable for class II
applications. The earth leakage current is below 100 μA what makes the units
suitable for BF (body floating) applications. The excellent efficiency of up to
94% allows a high power density for the standard 3" x 5" packaging format.
• High power density 3" x 5.8" encased medical power supply
• Protection class II prepared
• 450 Watt up to 65°C without derating, 320 Watt fanless operation without derating up to 50°C
• Medical certification to IEC/EN/ES 60601-1 edition 3.2 for 2 x MOPP
• EMC compliance to IEC/EN 60601-1-2 4th edition
• Risk management process according to ISO 14971 incl. risk management file
• Isolation (4000 VAC) and leakage current (<100 μA) rated for BF applications
• Standard features: 5 V standby output 12 V fan output, Remote On/Off, Power Good Signal, variable fan speed
• Operating up to 5000 m altitude
• 5-year product warranty
