TPP 450M Series
£0.00
SKU: TPP 450M Series
The TPP 450 Series of 450 Watt AC/DC power supplies feature a reinforced
double I/O isolation system according to latest medical safety standards
(60601-1 edition 3.2, 2 x MOPP). The earth leakage current is below 100 μA
what makes the units suitable for BF (body floating) applications. The excellent
efficiency of up to 94% allows a high power density for the standard 3" x 5"
packaging format.
• High power density 3" x 5.8" encased medical power supply
• 450 Watt up to 65°C without derating, 320 Watt fanless operation without derating up to 50°C
• Medical certification to IEC/EN/ES 60601-1 edition 3.2 for 2 x MOPP
• EMC compliance to IEC/EN 60601-1-2 4th edition
• Risk management process according to ISO 14971 incl. risk management file
• Acceptance criteria for electronic assemblies acc. to IPC-A-610 class 3
• Isolation (4000 VAC) and leakage current (<100 μA) rated for BF applications
• Standard features: 5 V standby output 12 V fan output, Remote On/Off, Power Good Signal, variable fan speed
• Operating up to 5000 m altitude
• 5-year product warranty
