THL 20WI Series
£0.00
SKU: THL 20WI
The THL 20WI series is the latest generation of dc-dc converter modules with highest power density. The product achieves 20 Watt output power while it comes in a metal case with dimensions of only 1.0”x 1.0”x 0.4”.
All models have an ultra wide 4:1 input voltage range and precisely regulated output voltages. Highest efficiency of up to 90% makes this product very reliable and appli-cable in temperature ranges of up to +75°C or +85°C with optional mounted heat sink. Typical applications are in mobile equipment, instrumentation, distributed power architectures in communication and industrial electronics and everywhere where space on the PCB is critical.
• Smallest encapsulated 20W converter!Ultra compact size: 1.0” x 1.0” x 0.4”
• Shielded metal case with isolated baseplate
• Ultrawide 4:1 input voltage ranges
• Very high efficiency up to 90%
• Output voltage adjustable
• Remote On/Off control
• Operating temp. range –40°C to +75°C and up to +85°C with heat-sink
• I/O isolation voltage 1500 VDC
• Lead free design, RoHS compliant
• 3-year product warranty
