TRI 20 Series
£0.00
SKU: TRI 20 Series
The new TRI 20 is a high isolation, regulated 20 Watt DC/DC converter series
which comes in a compact 2”x1” package. The core characteristic of the TRI 20
series is a sophisticated reinforced isolation system which is able to withstand
high test voltages (8000 VDC for 1s and 4200 VAC for 60s) and working
voltages (1000 VACrms). Complementing this isolation characteristic is a high
Common Mode Transient Immunity of 15 kV/μs. The new design allows to fully
integrate an EN 55032 class A filter and greatly reduces the no-load power
consumption. High efficiencies up to 90% allow safe operation from –40°C to
+55°C without derating and up to +76°C with derating. All models have a wide
2:1 input voltage range and precisely regulated, isolated output voltages. With
the latest IT safety certifications (IEC/EN/UL 62368-1) the TRI 20 series is the
perfect choice for many demanding applications in the industrial, transportation
and instrumentation sectors.
• Reinforced I/O-isolation 4200 VAC rated for 1000 VAC working voltage
• Ultra-high isolation peak voltage 8000 VDC (1s)
• Common Mode Transient Immunity (dv/dt) 15 kV/μs
• Operating temperature range -40 to +76°C
• Low no-load power consumption 240 – 480 mW
• Internal EN 55032 class A filter
• High efficiency up to 90%
• 2:1 input voltage range: 9-18, 18-36, 36-75 VDC
• Protection against overload, overvoltage and short circuit
• 3-year product warranty
