TRN 3 Series
£0.00
SKU: TRN 3-1-1
3 Watts single and dual output, 2:1 input range, Compact SIP package 11,9 x 7,7 x 11,0 mm
The TRN 3 Series comprises 3 Watt fully regulated, high performance DC/DC converters.
They come in a compact cubical package of only 1.00 cm3.
Full load operation is reliable up tp 65°C environment temperature. With 1’600 VDC I/Oisolation
voltage, and short current protection they cover a wide range of application when space is limited.
The input of the converters is designed for a wide voltage range (2:1) and minimum load is not required.
The functional I/O isolation system is designed to meet IEC/EN 62368-1 with a test voltage (60 s)
of 1600 VDC.
