TSP-BCM Series
£0.00
SKU: TSP-BCM Series
This module provides a professional battery management system to charge
and monitor an external lead-acid battery. Together with a power supply of
the TSP series, a perfect DC-UPS system can be configured. The connected
battery will be charged and held in charged mode by the power supply. In the
event of a mains power failure the battery will supply the output power until the
battery is discharged. As a consequence, the output voltage of the system is
equivalent to the battery voltage. To avoid overcharging the battery, an external
temperature sensor adjusts the battery voltage automatically to the required
end of charge voltage. This can extend the battery life.
The battery is protected against deep discharge. Mains power and battery status
are monitored regularly and failures indicated by corresponding LED’s and
alarm outputs. The module also provides an external On/Off input to switch-off
both, power supply and battery.
Battery protection for over voltage, deep discharge, short circuit and reverse connection
Alarm outputs for input, output and battery condition
Remote On/Off for battery and power supply
Controlled end of charge voltage by temperature sensor
International safety approval package
3-year product warranty
