TSR0.5 Series
£0.00
SKU: TSR 0.5 Series
TSR 0.5 is a series of step-down non-isolated switching regulators in compact SIP package. These converters are an ideal drop-in replacement to LM78 linear regulators when energy efficiency is a parameter of the design. The high efficiency up to 97% allows full load operation up to +80°C (+90°C with 50%load) ambient temperature without the need of forced air cooling.
Excellent output voltage accuracy and low standby current are other features that distinguish switching regulators from linear regulators.
• Compact SIP package
• Very high efficiency up to 97%
• Excellent line / load regulation
• Low standby current
• Operating temperature range –40 to 90°C
• Over-temperature protection
• Short circuit protection
• 3-year product warranty
